General FAQ

timeseries data = ohlcv(currentSymbol, currentExchange)
print("Analyzing:", currentSymbol, "on", currentExchange)


{% endfaqitem %}



{% faqitem question="Why do I get NaN when accessing historical data in early bars?" %}


kScript executes per-bar, meaning on each bar, only data up to that point is available. When you access historical data like `data[5]`, the first 4 bars will return NaN because there aren't 5 bars of history yet.

**Solution:** Always check for NaN or ensure enough historical data exists before using it in calculations. You can use the `barIndex` to make sure you're not accessing data too early.

timeseries trade = ohlcv(currentSymbol, currentExchange)

// Accessing 5 bars back
print(trade[5])

// Output on bars 0-3: NaN (not enough history)
// Output on bar 4 onwards: actual data from 5 bars ago


{% endfaqitem %}



{% faqitem question="Can I analyze multiple symbols in one script?" %}


Yes, but you need to explicitly specify each symbol:

timeseries btc_data = ohlcv("BTCUSDT", "BINANCE")
timeseries eth_data = ohlcv("ETHUSDT", "BINANCE")


{% endfaqitem %}



{% faqitem question="Can I write a script without source data?" %}


**No**, you cannot run a script without source data. kScript is designed for time-series analysis and requires data to create the timeline for bar-by-bar execution. Even if you declare sources but they return empty data, the script won't run because there are no bars to process.

// ✗ Won't produce any output
define("Empty Script", "onchart", true)
var value = 100
plotLine(value)  // Never executes because there are no bars

// ✓ Correct - with data source
define("Working Script", "onchart", true)
timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")
var value = ohlcvData.close
plotLine(value)  // Executes for each bar


{% endfaqitem %}



{% faqitem question="Can I subscribe to sources inside control structures (if/while/for)?" %}


**No**, you cannot call source functions inside control structures. Source subscriptions must be declared at the root level of your script in `timeseries` declarations.

**Why:** Sources need to be fetched and prepared before the script can execute. The runtime extracts source calls during the initialization phase, before the bar-by-bar loop begins. Dynamic source subscription during control flow would require async operations that aren't supported.

// ✓ Correct - at root level
timeseries ohlcv = source("ohlcv", "BTCUSDT", "BINANCE")

// ✗ Wrong - inside control structure
if (someCondition) {
  timeseries ohlcv = source("ohlcv", "BTCUSDT", "BINANCE")  // Won't work
}


{% endfaqitem %}



{% faqitem question="How do I access orderbook heatmap raw data?" %}


Orderbook data is accessed through specialized built-in functions that operate on orderbook timeseries sources. The data structure is `[timestamp, price1, amount1, price2, amount2, ...]` where positive amounts are bids and negative amounts are asks.

**Available functions:**

timeseries orderbookData = source("orderbook", "BTCUSDT", "BINANCE")

var totalBids = sumBids(orderbookData, depthPct=5)
var totalAsks = sumAsks(orderbookData, depthPct=5)
var bidAskRatio = totalBids / totalAsks

plotLine(value=bidAskRatio, width=2, colors=["blue"], label=["Bid/Ask Ratio"], desc=["Bid Ask Ratio"])


{% endfaqitem %}



{% faqitem question="How does kScript handle data gaps and interpolation?" %}


kScript fills data gaps with `NaN` values. The system creates a continuous timestamp array based on the interval, and when fetched data doesn't match the timeline length, gaps are pre-filled with `NaN`.

**Important:** For line plots, kScript will interpolate to connect points across gaps. For other use cases, if you need interpolation (forward fill, linear interpolation, etc.), you must implement it manually using custom logic.

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

 static lastValue = 0

var currentValue = ohlcvData.close
if (isnan(currentValue)) {
  currentValue = lastValue  // Forward fill
} else {
  lastValue = currentValue
}

plotLine(value=currentValue, width=2, colors=["blue"], label=["Current Value"], desc=["Current Value"])


{% endfaqitem %}


{% endfaqgroup %}

var safe_value = !isnan(sma_value) ? sma_value : 0


{% endfaqitem %}


{% endfaqgroup %}

plotLine(value=sma20, width=1, colors=["blue"], label=["SMA 20"], desc=["20-period Simple Moving Average"])
plotLine(value=sma50, width=2, colors=["red"], label=["SMA 50"], desc=["50-period Simple Moving Average"])


{% endfaqitem %}



{% faqitem question="Can I plot conditional signals?" %}


Yes, use ternary operators or conditional values:

var buy_signal = crossover(sma_fast, sma_slow)
plotShape(value=buy_signal ? data.low : na, shape="circle", width=2, colors=["green"], label=["Buy Signal"], desc=["Buy Signal Marker"])


{% endfaqitem %}



{% faqitem question="How do I change plot colors dynamically?" %}


Use the `colorIndex` parameter:

var trend = sma_fast > sma_slow ? 1 : 0
plotLine(value=data.close, width=2, colors=["red", "green"], colorIndex=trend, label=["Price"], desc=["Price with Dynamic Colors"])


{% endfaqitem %}



{% faqitem question="Can I call plot functions inside conditionals (if-else) or loops?" %}


**Conditionals (if-else): Yes** - You can call plot functions inside if-else statements. The plot will execute conditionally based on the condition at each bar.

**Loops: Not allowed** - Plotting inside loops would create multiple plot outputs per bar, which is not the intended behavior and may cause unexpected results.

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// ✓ Allowed in conditionals
if (ohlcv.close > ohlcv.open) {
  plotLine(value=ohlcvData.close, width=2, colors=["green"], label=["Bullish"], desc=["Bullish Price"])
} else {
  plotLine(value=ohlcvData.close, width=2, colors=["red"], label=["Bearish"], desc=["Bearish Price"])
}

// ✗ Not recommended in loops
for (var i = 0; i < 10; i++) {
  plotLine(value=i, width=1, colors=["blue"], label=["Loop"], desc=["Loop Value"])  // Creates multiple plots per bar
}


{% endfaqitem %}



{% faqitem question='Difference between plotLine() and plot(plotType="line")?' %}


There is **NO functional difference**. `plot()` with `plotType="line"` is simply an alias that internally calls `plotLine()`. The `plot()` function is a generic interface that can create different plot types by changing the `plotType` parameter.

**Available plot types via `plot()`:**

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// These three are identical
plotLine(value=ohlcvData.close, width=2, colors=["blue"], label=["Price"], desc=["Close Price"])
plot(value=ohlcvData.close, plotType="line", width=2, colors=["blue"], label=["Price"], desc=["Close Price"])
plot(value=ohlcvData.close, plotType="spline", width=2, colors=["blue"], label=["Price"], desc=["Close Price"])

// plot() can also create other types
plot(value=ohlcvData.close, plotType="bar", width=1, colors=["green"], label=["Volume"], desc=["Volume Bars"])
plot(value=[ohlcvData.open, ohlcvData.high, ohlcvData.low, ohlcvData.close], plotType="candle", width=1, colors=["red", "green"], label=["OHLC"], desc=["OHLC Candlestick"])


{% endfaqitem %}



{% faqitem question="How does the positioning system work for shape and text plots?" %}


Shape and text plots use a coordinate-based positioning system with price (y-axis) and time (x-axis):

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// Plot shape at high price
if (ohlcvData.close > ohlcvData.open) {
  plotShape(value=ohlcvData.high, shape="circle", width=3, colors=["green"], label=["Bullish"], desc=["Bullish Signal"])
}

// Plot text at specific price level
plotText("Signal", "yellow", ohlcvData.close, size=12, fill=true, backgroundColor="black")

// Plot range between two points
var prevTime = time() - (60 * 60 * 1000)  // 1 hour ago
plotRange(prevTime, ohlcvData.low, time(), ohlcvData.high, color="blue", fillColor="rgba(0,0,255,0.2)")


{% endfaqitem %}


{% endfaqgroup %}

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// ✗ Wrong - null becomes 0
var value1 = isnan(ohlcvData.close) ? null : ohlcvData.close
plotLine(value1)  // Will plot 0 for missing data

// ✓ Correct - use NaN
var value2 = isnan(ohlcvData.close) ? NaN : ohlcvData.close
plotLine(value2)  // Will show gap for missing data


{% endfaqitem %}


{% endfaqgroup %}

switch (signal) {
  case "buy": {
    plotShape(value=data.low, shape="arrowUp", location="belowBar", colors=["#16a34a"])
  }
  case "sell": {
    plotShape(value=data.high, shape="arrowDown", location="aboveBar", colors=["#dc2626"])
  }
  default: {
    // no-op
  }
}

`if-else` chains remain fully supported:

// ✓ Use if-else chains instead
if (signal == "buy") {
  plotShape(value=data.low, shape="circle", width=2, colors=["green"], label=["Buy"], desc=["Buy Signal"])
} else if (signal == "sell") {
  plotShape(value=data.high, shape="circle", width=2, colors=["red"], label=["Sell"], desc=["Sell Signal"])
} else if (signal == "hold") {
  // Do nothing
} else {
  // Default action
}


{% endfaqitem %}



{% faqitem question="Are objects and arrays supported in kScript?" %}


**Arrays: Partial support** - Arrays are supported with type restrictions. Arrays must contain elements of the same type (homogeneous arrays).

**Supported array types:**

type Zone { top: number, bottom: number, touches: number }
persist zones = []
zones.push(Zone.new(top=high, bottom=low, touches=0))

// ✓ Homogeneous arrays
var colors = ["red", "green", "blue"]
var prices = [100, 200, 300]

// ✓ Array of timeseries values
var ohlc = [ohlcv.open, ohlcv.high, ohlcv.low, ohlcv.close]
plotCandle(value=ohlc, width=1, colors=["green", "red"], label=["OHLC"], desc=["OHLC Candlestick"])

// ✗ Mixed type arrays not allowed
var mixed = [100, "hello", true]  // Error

// ✓ Object for constraints (limited support)
var userLength = input("Length", "number", defaultValue=14, constraints={min:1, max:100})


{% endfaqitem %}



{% faqitem question="Can a script get signals from another script or indicator?" %}


**No**, kScript v3 does NOT currently support cross-script communication. Each script runs in isolation and cannot access data or signals from other scripts. Each script has its own runtime context, data manager, variable environment, and series storage.

**Note:** Cross-script communication will be added as a feature soon.

**Workaround:** Use shared data sources. Both scripts can subscribe to the same source data and process it independently. Alternatively, combine the logic of multiple indicators into a single script.

// ✗ Cannot access signals from other scripts
// var otherRSI = getScriptValue("RSI Indicator", "rsi")  // Not supported

// ✓ Workaround: Combine logic in a single script
define("Combined Indicator + Strategy", "onchart", true)
timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// Calculate indicator
var rsiData = rsi(ohlcvData.close, period=14)

// Use indicator for strategy
if (rsiData > 70) {
  plotShape(value=ohlcvData.high, shape="circle", width=5, colors=["red"], label=["Overbought"], desc=["Overbought Signal"])
} else if (rsiData < 30) {
  plotShape(value=ohlcvData.low, shape="circle", width=5, colors=["green"], label=["Oversold"], desc=["Oversold Signal"])
}

plotLine(value=rsiData, width=2, colors=["purple"], label=["RSI"], desc=["Relative Strength Index"])


{% endfaqitem %}



{% faqitem question="Can I use timeseries in custom functions and control structures?" %}


**Yes and No**, with important constraints:

**Custom Functions:**

timeseries ohlcvData = source("ohlcv", "BTCUSDT", "BINANCE")

// Custom function with timeseries parameter
func calculateRange(data) {
  var high = data.high
  var low = data.low
  return high - low
}

// Use in control structure
if (ohlcvData.close > ohlcvData.open) {
  var range = calculateRange(ohlcvData)
  plotLine(value=range, width=2, colors=["green"], label=["Range"], desc=["Price Range"])
} else {
  plotLine(value=0, width=2, colors=["red"], label=["Zero"], desc=["Zero Line"])
}


{% endfaqitem %}



{% faqitem question="Does kScript support alerts?" %}


**No**, kScript does not currently support alerts. Alert functionality is yet to be implemented for kScripts.

{% endfaqitem %}



{% faqitem question="Can trades be executed from kScript?" %}


**No**, kScript does not support trade execution. kScript is designed for analysis and visualization purposes only. You cannot place orders, execute trades, or interact with exchange APIs for trading directly from kScript.

{% endfaqitem %}


{% endfaqgroup %}

// Good: Calculate once
static fibonacci_level = 0.618

// Avoid: Recalculating every bar
var fibonacci_level = 618 / 1000


{% endfaqitem %}


{% endfaqgroup %}

var number = 42
var sma_val = sma(number, 14)  // Wrong: number is not timeseries

timeseries prices = ohlcv(currentSymbol, currentExchange)
var sma_val = sma(prices.close, 14)  // Correct


{% endfaqitem %}


{% endfaqgroup %}
